Hager h3+ P250 Energy 3P3D 40A 50kA MCCB for reliable protection of industrial/commercial feeders. Rated 220-690 V, Icu up to 65 kA (240 V) and 50 kA (400/415 V), Uimp 8 kV. ENERGY trip with adjustable long-time delays, short-time (Isd 1.5-10 In, 50-400 ms), and instantaneous (3-15 In). Fixed 3-pole, IP4X, interlockable, 10k electrical/40k mechanical ops. Suits Cu/Al 35-185 mm².

EAN

3250613141790

VPE

1 piece

Data Act Notice

Moulded case circuit breakers

Moulded Case Circuit Breaker 4P 40A Icu 50kA Energy h3+ P250 HMT040NR

Accessories
Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

product.page.accessories.title

Mechanic accessories for low-voltage components 1 product.page.accessories.products-available
Shunt release 5 product.page.accessories.products-available
Connection Functions 7 product.page.accessories.products-available
Handle with interlock for power breaker 1 product.page.accessories.products-available
DC power supply 1 product.page.accessories.products-available
Handle for power circuit breaker 1 product.page.accessories.products-available

Technical characteristics

Rated current IN

40 A
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-2

50 kA
Rated ultimate short-circuit breaking capacity Icu under 240 V AC IEC 60947-2

65 kA
Rated ultimate short-circuit breaking capacity Icu under 415 V AC IEC 60947-2

50 kA
Rated ultimate short-circuit breaking capacity Icu under 690 V AC IEC 60947-2

6 kA
Rated service breaking capacity Ics under 220 V AC according to IEC 60947-2

65 kA
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-2

65 kA
Rated service breaking capacity Ics under 240 V AC according to IEC 60947-2

65 kA
Rated service breaking capacity Ics under 380 V AC according to IEC 60947-2

50 kA
Rated service breaking capacity Ics under 400 V AC according to IEC 60947-2

50 kA
Rated service breaking capacity Ics under 415 V AC according to IEC 60947-2

50 kA
Rated service breaking capacity Ics under 690 V AC according to IEC 60947-2

6 kA
Rated current at 10°C according to IEC 60947

40 A
Rated current at 15°C according to IEC 60947

40 A
Rated current at 20°C according to IEC 60947

40 A
Rated current at 25°C according to IEC 60947

40 A
Rated current at 30°C according to IEC 60947

40 A
Rated current at 35°C according to IEC 60947

40 A
Rated current at 40°C according to IEC 60947

40 A
Rated current at 45°C according to IEC 60947

40 A
Rated current at 50°C according to IEC 60947

40 A
Rated current at 55°C according to IEC 60947

40 A
Rated current at 60°C according to IEC 60947

40 A
Rated current at 65°C according to IEC 60947

40 A
Rated current at 70°C according to IEC 60947

40 A

Number of poles

3
Control/operation element

Toggle
Device construction type

Fixed built-in
Neutral position

Without neutral

Frequency

50 - 60 Hz

Rated impulse withstand voltage Uimp

8000 V
Rated insulation voltage Ui

800 V
Rated operational voltage Ue

220 - 690 V

Trip unit

ENERGY

Power dissipation at IN

1.14 W

Electric endurance in number of cycles

10000
Number of mechanical operations

40000

Nominal tightening torque

12 - 12 Nm
Mounting-/Connection Position

Front

Ingress Protection (IP) class

IP4X

Cross-section flexible conductor

35 - 150 mm²
Cross-section rigid conductor

35 - 185 mm²

Interlockable

Yes

Cable material

Copper, Aluminium

Compatible with RDC AOB

No
Suitable for DIN Rail

No
Suitable for distribution board

Yes

Is generating data

Yes
Data types

Alarms, Basic information, Device energy management, Electrical measurement, Detailed electrical measurement, General diagnostics, Network diagnostics, Operational state, Software diagnostics
Data formats

MODBUS (RTU)
Estimated daily data volume

< 1 KB
Real time data generation

No
Data stored on device

No

Height

165 mm
Width

105 mm
Depth

97 mm

Adjustment range short-term delayed short-circuit release

24 - 400 A

Long-time overload protection (ltd): delay (tr)

0.5 s, 1.5 s, 2.5 s, 5 s, 7.5 s, 9 s, 10 s, 12 s, 14 s, 16 s
Short-time protection (std): current (Isd)

1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5, 5.5, 6, 6.5, 7, 7.5, 8, 8.5, 9, 9.5, 10
Short-time protection (std): delay (tsd)

50 ms, 100 ms, 200 ms, 300 ms, 400 ms
Instantaneous protection (li): dial setting coefficient

3, 3.5, 4, 4.5, 5, 5.5, 6, 6.5, 7, 7.5, 8, 8.5, 9, 9.5, 10, 10.5, 11, 11.5, 12, 12.5, 13, 13.5, 14, 14.5, 15
