The Hager 24 V DC undervoltage release for x160/P160, x250/P250 and x630/P630 breakers trips the breaker when control voltage is lost, boosting safety and enabling emergency-stop and remote interlocking. IP4X rated, it draws just 0.56 VA inrush with 0.60 W power loss, operates at 24 V DC, and has no delay. Ideal for reliable protection in industrial and commercial switchboards.
EAN
3250613346362
Packaging
1 Piece
Undervoltage release delayed 380-450V AC IP4X for x160-P160-x250-P250 HXA011H
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Power
-
Inrush power absorbed0.56 VA
-
Total power loss under IN0.60 W
Safety
-
Ingress Protection (IP) classIP4X
Voltage
-
Command voltage AC0 - 0 V
-
Command voltage DC24 - 24 V
Functions
-
DelayedNo
