Insulated busbar 3P 80A fork 16mm² 12M KDN380A
EAN
3250613741006
Packaging
50 PCEs
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Number of poles3 P
-
Type of pole3 P
Compatibility
-
Intended for the compatible referencesModular devices
Main electrical features
-
Rated operational voltage Ue230 / 400 V
Voltage
-
Max operating voltage400 V
Electric current
-
Rated current80 A
Dimensions
-
Length210 mm
-
Pitch17.8 mm
Installation, mounting
-
Suitable to a device with an auxiliaryNo
Connection
-
Connection cross-sect. rigid cable16mm²
-
Suitable for product with neutral busbarNo
-
Connector typebusbar fork
-
Type of connectionwith screw / quick connect
Equipment
-
Number of connections12 C
Safety
-
REACH conformNo
-
RoHS conformYes
Use conditions
-
InsulatedYes
