Moulded case circuit breakers (MCCB)

Moulded Case Circuit Breaker h3+ P250 TM ADJ 4P4D N0-100% 125A 50kA FTC HMT126DR

Accessories
Technical characteristics
Environmental value
Documentations
More products

Download the sheet

Complete your system

Auxiliaries contact block 5 products available
Motor operator 17 products available
Auxiliaries switch position 1 products available
Door coupling handle 1 products available
Under voltage coil 3 products available
Connection Functions 1 products available

Technical characteristics

Rated current

125 A
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-2

50 kA
Rated ultimate short-circuit breaking capacity Icu under 240 V AC IEC 60947-2

65 kA
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-2

65 kA
Rated service breaking capacity Ics under 400 V AC according to IEC 60947-2

50 kA
Rated ultimate short-circuit breaking capacity Icu under 660 V AC IEC 60947-2

6 kA
Rated ultimate short-circuit breaking capacity Icu under 690 V AC IEC 60947-2

6 kA
Rated current 10°C according to IEC 60947

151.70 A
Rated current 15°C according to IEC 60947

148.60 A
Rated current 20°C according to IEC 60947

145.50 A
Rated current 25°C according to IEC 60947

142.30 A
Rated current 30°C according to IEC 60947

139 A
Rated current at 35°C according to IEC 60947

135.60 A
Rated current at 40°C according to IEC 60947

132.20 A
Rated current 45°C according to IEC 60947

128.60 A
Rated current 50°C according to IEC 60947

125 A
Rated current 55°C according to IEC 60947

121.30 A
Rated current at 60°C according to IEC 60947

117.40 A
Rated current 65°C according to IEC 60947

113.40 A
Rated current 70°C according to IEC 60947

109.30 A

Number of poles

4
Control/operation element

Toggle
Device construction type

Fixed built-in
Neutral position

Left

Frequency

50 - 60 Hz

Rated impulse withstand voltage Uimp

8,000 V
Rated insulation voltage Ui

800 V
Rated operational voltage Ue

220 - 690 V

Trip unit

TM A/A

Total power loss under IN

27.90 W

Electric endurance in number of cycles

10,000
Number of mechanical operations

40,000

Ingress Protection (IP) class

IP4X

Cross-section flexible conductor

35 - 150 mm²
Cross-section rigid conductor

35 - 185 mm²

Interlockable

Yes

Thermal protection knob setting xIN

0.63, 0.8, 1

Cable material

Copper, Aluminium

Compatible with RDC AOB

Yes
Suitable for DIN Rail

No
Suitable for distribution board

Yes

Height

165 mm
Width

140 mm
Depth

97 mm
Downstream busbar: width, height, diameter screw (max.)

4 mm, 8.5 mm, 25 mm
Top stream busbar: width, height, diameter screw (max.)

4 mm, 8.5 mm, 25 mm

Instantaneous protection (li): dial setting coefficient

6, 8, 10, 13

Mounting-/Connection Position

Front
Nominal tightening torque

12 - 12 Nm
Nominal tightening torque down terminal

12 - 12 Nm
Nominal tightening torque top terminal

12 - 12 Nm

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes
