Moulded Case Circuit Breaker h3+ P160 TM ADJ 3P3D 125A 25kA CTC HHS125DC

Name: HHS125DC
Brand: Hager
SKU: HHS125DC20

EAN-Nr.

3250613178017

Packaging

1 piece

Accessories
Technical characteristics
Environmental value
Documentations
More products

Download the sheet

Complete your system

Under voltage coil 3 products available
Shunt release 1 products available
Auxiliaries contact block 5 products available
Connection Functions 4 products available
Auxiliaries cable adaptor 1 products available
Terminal cover 2 products available

Technical characteristics

Rated current

125 A
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-2

25 kA
Rated ultimate short-circuit breaking capacity Icu under 240 V AC IEC 60947-2

35 kA
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-2

35 kA
Rated service breaking capacity Ics under 400 V AC according to IEC 60947-2

25 kA
Rated current 10°C according to IEC 60947

146.90 A
Rated current 15°C according to IEC 60947

144.30 A
Rated current 20°C according to IEC 60947

141.70 A
Rated current 25°C according to IEC 60947

139.10 A
Rated current 30°C according to IEC 60947

136.40 A
Rated current at 35°C according to IEC 60947

133.60 A
Rated current at 40°C according to IEC 60947

130.80 A
Rated current 45°C according to IEC 60947

127.90 A
Rated current 50°C according to IEC 60947

125 A
Rated current 55°C according to IEC 60947

122 A
Rated current at 60°C according to IEC 60947

118.90 A
Rated current 65°C according to IEC 60947

115.70 A
Rated current 70°C according to IEC 60947

112.50 A

Number of poles

3
Control/operation element

Toggle
Device construction type

Fixed built-in
Neutral position

Without neutral

Frequency

50 - 60 Hz

Rated impulse withstand voltage Uimp

8,000 V
Rated insulation voltage Ui

800 V
Rated operational voltage Ue

220 - 690 V

Trip unit

TM A/A

Total power loss under IN

32.10 W

Electric endurance in number of cycles

10,000
Number of mechanical operations

40,000

Ingress Protection (IP) class

IP4X

Cross-section flexible conductor

6 - 70 mm²
Cross-section rigid conductor

6 - 95 mm²

Type of connection

Screw terminal

Interlockable

Yes

Thermal protection knob setting xIN

0.63, 0.8, 1

Cable material

Copper

Compatible with RDC AOB

No
Suitable for DIN Rail

No
Suitable for distribution board

Yes

Height

130 mm
Width

90 mm
Depth

97 mm

Instantaneous protection (li): dial setting coefficient

6, 8, 10, 12

Mounting-/Connection Position

Front
Nominal tightening torque

6 - 6 Nm
Nominal tightening torque down terminal

6 - 6 Nm
Nominal tightening torque top terminal

6 - 6 Nm
