Motion detector corridor 360° surface mounted NO contact detection 5x30m EER515
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Detection
-
Detection angle360 - 360
-
Type of sensorMovement detector
-
Detection angle horizontal0 - 0
Settings
-
Switch off delay time0
-
Switch on delay time0
Lighting
-
LED lamp power400 W
-
Photocell sensitivity5 - 2,000 lx
Connection
-
Connector/plug typePlug-in terminal
Frequency
-
Frequency50 - 60 Hz
Dimensions
-
Built-in depth78 mm
-
Installation height2.50 - 2.50 m
Materials
-
MaterialPlastic
-
Surface finishMatt
Safety
-
Ingress Protection (IP) classIP41
Installation, mounting
-
Mounting onSurface mounting
-
Ceiling mounting possibleYes
Reach distance
-
Max. transmission range frontally5 m
-
Max. transmission range sideways10 m
