cubyko Socket 2P+E screwless flush mounted grey IP55 WNE100
EAN
3250617172004
Packaging
10
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Compatible products
-
Referenced by 19 products available
Referenced by
-
WNA408Bcubyko Double vertical flush adapter white IP55
-
WNA681BSurface-mounted lower casing 1gang with frame and cable entries W.1 polar white
-
WNA402Bcubyko Double horizontal flush adapter white IP55
-
WNA682Bcubyko Double horizontal box empty with 2 sliders white IP55
-
WNA683Bcubyko Triple horizontal box empty white IP55
-
WNA683cubyko Triple horizontal box empty grey IP55
-
WNA403Bcubyko Triple horizontal flush adapter white IP55
-
WNA401cubyko Single flush adapter composable grey IP55
-
WNA403cubyko Triple horizontal flush adapter grey IP55
-
WNA686Bcubyko Double vertical box empty white IP55
-
WNA401Bcubyko Single flush adapter composable white IP55
-
WNA408cubyko Double vertical flush adapter grey IP55
-
WNA403
cubyko Triple horizontal flush adapter grey IP55
-
WNA402cubyko Double horizontal flush adapter grey IP55
-
WNA682cubyko Double horizontal box empty with 2 sliders grey IP55
-
WNA685cubyko Double horizontal box empty with 4 sliders grey IP55
-
WNA685Bcubyko Double horizontal box empty with 4 sliders white IP55
-
WNA686cubyko Double vertical box empty grey IP55
-
WNA682
cubyko Double horizontal box empty with 2 sliders grey IP55
Technical properties
Electric current
-
Rated current16 A
Voltage
-
Nominal voltage250 - 250 V
Frequency
-
Frequency50 - 60 Hz
Materials
-
ColourGrey
-
RAL code7011
-
Surface finishSatin finish
-
MaterialPolycarbonate (PC)
-
TreatmentVarnished
Dimensions
-
Height75 mm
-
Width75 mm
-
Depth22.80 mm
Installation, mounting
-
Mounting onFlush mounting
Connectivity
-
Type of connectionPlug-in connection
-
Mounting typeScrew mounting
Equipment
-
Connector/plug type socket outletFrench norm NF
-
Rotated central insertNo
-
With hinged lidYes
-
With round protective earth pinYes
-
With signal lampNo
Cover, door
-
Type of lidSelf-closing hinged cover, can be arrested in end position
Capacity
-
Number of modules2
Safety
-
With enhanced contact protectionNo
-
Impact resistance IKIK07
-
Ingress Protection (IP) classIP55
Functions
-
With orientation lightingNo
-
Related SystemsHager cubyko
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
undefined
PDF -
Declaration of conformity
Declaration of conformity International 2021-07-14
PDF111,30 kB
