Hager BG113 bar/cable-through current transformer 200/5 A, 2.5 VA, Class 1 for accurate metering and protection in LV panels. Plug-in design with 20×29.5 mm window; wire connection 1.5-6 mm². 50-60 Hz, max 720 V, 3 kV withstand, FS5. Robust: Ith 60×Ipr/1 s, Idyn 2.5×Ith, Icth 1.2×Ipr. Operates -40 to 40 °C. Compact (70×49.5×30 mm). Mounts on DIN rail or plate. Ideal for busbar or cable applications.

EAN

4049857139347

VPE

1 piece

Bar/Cable-through Current Transformer 250/5A 2.5VA Class 1 Plug-in BG113 SRA02005

Accessories
Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

product.page.accessories.title

DIN rail adapter 1 product.page.accessories.products-available

Technical characteristics

Filter Type product

Plug-in current transformer

Accuracy class

1

Power

2.50 VA
Power dissipation at IN

2.20 W

Height

70 mm
Width

49.50 mm
Depth

30 mm
Height of opening

20 mm
Width of opening

29.50 mm

Type of connection

Wire connection

Frequency

50 - 60 Hz

Rated power-frequency withstand voltage (r.m.s.)

3000 V
Max. operating voltage

720 V

Operating temperature

-40 - 40 °C
Storage/transport temperature

-40 - 40 °C

Cross-section flexible conductor

1.5 - 6 mm²
Cross-section rigid conductor

1.5 - 6 mm²

Ingress Protection (IP) class

IP10
Insulating class

E

Rated primary current (Ipr)

200 A
Rated secondary current (Isr)

5 A
Rated current IN

200 A
Rated continuous thermal current

1,2*Ipr
Rated short-time thermal current (Ith/1s)

60*Ipr
Rated dynamic current

2.5*Ith
Over voltage limiting factor

FS 5

Mounting on

DIN rail, Mounting plate

catalog.pageproduct.title_sustainability.h2

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes

Halogen free Yes
