The Hager BG113 bar/cable-through current transformer delivers Class 1 accuracy at 75/5 A, 1.5 VA for metering and protection in LV panels. Plug-in, wire connection, 20×29.5 mm window, DIN rail or plate mounting. 50-60 Hz, up to 720 V, 3 kV withstand. Robust ratings: 1.2×In continuous, 60×In/1 s thermal, 2.5×Ith dynamic, FS5. Compact 70×49.5×30 mm, -40 to 40°C, 0.8 W loss. Reliable, space-saving current capture on bars or cables.

EAN

4049857139293

VPE

1 piece

Plug-in Bar/Cable-through Current Transformer 100/5A 2.5VA Class 1 20mm SRA00755

Accessories
Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

product.page.accessories.title

DIN rail adapter 1 product.page.accessories.products-available

Technical characteristics

Filter Type product

Plug-in current transformer

Accuracy class

1

Power

1.50 VA
Power dissipation at IN

0.80 W

Height

70 mm
Width

49.50 mm
Depth

30 mm
Height of opening

20 mm
Width of opening

29.50 mm

Type of connection

Wire connection

Frequency

50 - 60 Hz

Rated power-frequency withstand voltage (r.m.s.)

3000 V
Max. operating voltage

720 V

Operating temperature

-40 - 40 °C
Storage/transport temperature

-40 - 40 °C

Cross-section flexible conductor

1.5 - 6 mm²
Cross-section rigid conductor

1.5 - 6 mm²

Ingress Protection (IP) class

IP10
Insulating class

E

Rated primary current (Ipr)

75 A
Rated secondary current (Isr)

5 A
Rated current IN

75 A
Rated continuous thermal current

1,2*Ipr
Rated short-time thermal current (Ith/1s)

60*Ipr
Rated dynamic current

2.5*Ith
Over voltage limiting factor

FS 5

Mounting on

DIN rail, Mounting plate

catalog.pageproduct.title_sustainability.h2

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes

Halogen free Yes
