The Hager LFS steel trunking 60x60 mm in traffic white (RAL 9016) delivers robust, neat cable management for residential and commercial installs. Supplied in 2 m lengths with 2860 mm² inner cross-section, it holds up to 12 Ø11 mm cables (50% fill). Varnished steel, IK08 impact resistance, IP30. Single compartment, cable retaining clip included. Operating temperature -5 to 90°C. Couplers available as separate reference.
EAN
4012740994484
Packaging
8 Meters
Overlapping T-piece Steel for LFS 40x60 Trunking RAL9016 IK08 IP30 LFS6006009016
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Cable clip/retainer for installation duct 2 products available -
Earthing set 1 products available -
Coupler for installation duct 1 products available -
End piece for installation duct 1 products available -
Internal corner for installation duct 1 products available -
External corner for installation duct 1 products available
Complete your system
Technical properties
Dimensions
-
Height60 mm
-
Width60 mm
-
Length2000 mm
-
Inner cross-section2860 - 2860 mm²
Cover, door
-
Type of lidLoose
Capacity
-
Max. number of cables (Ø11mm, 50% filled, without devices)12
Materials
-
MaterialSteel
-
TreatmentVarnished
-
RAL code9016
-
ColourTraffic white
-
TransparentNo
Safety
-
Impact resistance IKIK08
-
Ingress Protection (IP) classIP30
Standards
-
Suitable for functional integrity according to DIN4102-12No
Use conditions
-
Operating temperature-5 - 90 °C
Connectivity
-
Trunking couplingCouplers as separate reference
Equipment
-
Number of partitions0
-
Number of compartments1 - 1
-
Number of pluggable partitions0
-
Cable retaining clip includedYes
-
Number of cable retainers per meter2
-
With protective filmNo
Configuration
-
With antibacterial treatmentNo
Scope of delivery
-
Delivery on rollNo
Environmental value
