The Hager motorized transfer switch 4P 1600A ensures automatic, reliable source changeover for large LV installations. Rated 380-415 V and 1600 A, it handles up to 1.053 MW at 400 V AC-1 and withstands 100 kA with gG fuses. Four-pole, fixed built-in design for mounting plate, suited to distribution boards (not DIN rail). Ideal for mains/backup generator switching with high continuity and safety.
EAN
3250613191436
Packaging
1 Piece
Motorized transfer switch 4P 1000A 50kA Fixed built-in Mounting plate HIB492M
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Accessories/spare parts for low-voltage switch technology 3 products available -
Controller for automatic transfer switch 1 products available
Compatible products
-
Referenced by 1 products available
Technical properties
Voltage
-
Rated operational voltage Ue380 - 415 V
Electric current
-
Rated current1600 A
-
Rated conditional short-circuit current Icc with gl-gG fuses100 kA
Power
-
Rated operational power under 400 V AC AC11053000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Installation, mounting
-
Mounting onMounting plate
