The Hager motorized transfer switch 4P 250A ensures reliable source changeover between mains and backup for critical loads. Rated 380-415 V and 250 A with 50 kA Icc (gl/gG fuses) and 164 kW at 400 V AC-1, it delivers high fault withstand and smooth, remote/automatic switching. Fixed built-in design for mounting plate, suitable for distribution boards (not DIN rail), ensuring continuity and safety.
EAN
3250613191375
VPE
1 piece
ATS Energy Management 4P 800A 50kA 380-415V AC1 526kW Fixed HIB425M
catalog.lists.product_addition.login_popup.title
catalog.lists.product_addition.login_popup.descriptive_text
product.page.accessories.title
product.page.accessories.associated-products
-
Accessories/spare parts for low-voltage switch technology 3 product.page.accessories.products-available -
Terminal cover 1 product.page.accessories.products-available -
Controller for automatic transfer switch 1 product.page.accessories.products-available
product.page.accessories.compatible.title
-
product.page.accessories.referenced_by.title 1 product.page.accessories.products-available
product.page.accessories.referenced_by.title
Technical characteristics
Voltage
-
Rated operational voltage Ue380 - 415 V
Electric current
-
Rated current IN250 A
-
Rated conditional short-circuit current Icc with gl-gG fuses50 kA
Power
-
Rated operational power under 400 V AC AC1164000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Installation, mounting
-
Mounting onMounting plate
