The Hager motorized transfer switch 4P 800A ensures automatic, safe switching between power sources for large commercial and industrial loads. Rated 380-415 V, 800 A and 526 kW (AC1 at 400 V), it withstands 50 kA with gG fuses. Four-pole, fixed built-in design mounts on a plate in distribution boards (not DIN rail). Delivers reliable continuity and protection under high fault conditions.
EAN
3250613191405
Packaging
1 Piece
Motorized transfer switch 4P 400A 50kA 380-415V Fixed built-in HIB480M
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Accessories/spare parts for low-voltage switch technology 3 products available -
Controller for automatic transfer switch 1 products available
Compatible products
-
Referenced by 1 products available
Technical properties
Voltage
-
Rated operational voltage Ue380 - 415 V
Electric current
-
Rated current800 A
-
Rated conditional short-circuit current Icc with gl-gG fuses50 kA
Power
-
Rated operational power under 400 V AC AC1526000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Installation, mounting
-
Mounting onMounting plate
