The Hager motorized transfer switch 4P 200A ensures automatic, reliable switching between power sources for three-phase + neutral systems. Rated 200 A up to 690 V, it handles 131 kW at 400 V AC1 and withstands 50 kA with gG fuses. Fixed built-in for mounting-plate installation in distribution boards (not DIN-rail), it secures continuity for commercial and industrial loads demanding robust isolation and high fault capacity.
EAN
3250613191368
Packaging
1 Piece
Automatic Transfer Switch 4P 250A Icc 50kA Energy Management 380-415V HIB420M
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Accessories/spare parts for low-voltage switch technology 2 products available -
Controller for automatic transfer switch 1 products available
Compatible products
-
Referenced by 1 products available
Technical properties
Voltage
-
Rated operational voltage Ue380 - 690 V
Electric current
-
Rated current200 A
-
Rated conditional short-circuit current Icc with gl-gG fuses50 kA
Power
-
Rated operational power under 400 V AC AC1131000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Installation, mounting
-
Mounting onMounting plate
