The Hager 4P 630A change-over switch ensures safe transfer between two power sources for large LV installations. Rated Ui 1000 V, Uimp 12 kV, AC‑1 414 kW at 400 V. With Icw 17 kA and Icc 50 kA (with gG fuses), it offers strong fault endurance. Long rotary handle and interlockable safety. 50-60 Hz, -20…70°C. Accepts 2×185 mm² conductors per pole. IP00 for enclosure mounting. Ideal for mains/backup switching.
EAN
3250613190057
Packaging
1 Piece
Change-over switch 4P 800A Ui 1000V Icw 64kA IP00 Long rotary handle HI458
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Terminal cover 2 products available -
Auxiliary contact block 1 products available -
Accessories/spare parts for low-voltage switch technology 1 products available -
Door coupling handle for switchgear 1 products available -
Switch operating shaft 2 products available
Technical properties
Voltage
-
Rated insulation voltage Ui1000 V
-
Rated impulse withstand voltage Uimp12000 V
Electric current
-
Rated current630 A
-
Rated short-time withstand current Icw IEC 6094717 kA
-
Rated conditional short-circuit current Icc with gl-gG fuses50 kA
Power
-
Rated operational power under 400 V AC AC1414000 W
-
Total power loss under IN129.60 W
Architecture
-
Number of poles4
-
Control/operation elementLong rotary handle
-
Type of pole4P
Dimensions
-
Height260 mm
-
Width379 mm
-
Depth295 mm
Controls and indicators
-
Motor drive integratedNo
Cover, door
-
InterlockableYes
Safety
-
Ingress Protection (IP) classIP00
Capacity
-
Number of modules12
Frequency
-
Frequency50 - 60 Hz
Use conditions
-
Operating temperature-20 - 70 °C
Connection
-
Cross-section rigid conductor2x 185 mm²
