MCB 2P 10kA/15kA C-40A 2M NCN240A

product.page.accessories.title

Modular phase busbar 2 product.page.accessories.products-available
Locking interlocking functions 1 product.page.accessories.products-available
Phase separation functions 1 product.page.accessories.products-available
Terminal cover 1 product.page.accessories.products-available
Mechanic accessories for low-voltage components 1 product.page.accessories.products-available
Shunt release 1 product.page.accessories.products-available

Rated current IN

40 A
Rated short-circuit breaking capacity Icn under 230 V AC according to IEC 60898-1

20 kA
Rated ultimate short-circuit breaking capacity Icu AC IEC 60947-2

15 kA
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-2

15 kA
Rated current at -15°C

57.27 A
Rated current at -10°C

55.35 A
Rated current at -5°C

53.43 A
Rated current at 0°C

51.51 A
Rated current at 5°C

49.59 A
Rated current at 10°C

47.68 A
Rated current at 15°C

45.76 A
Rated current at 20°C

43.84 A
Rated current at 25°C

41.92 A
Rated current at 30°C

40 A
Rated current at 35°C

38.75 A
Rated current at 40°C

37.5 A
Rated current at 45°C

36.24 A
Rated current at 50°C

34.99 A
Rated current at 55°C

33.74 A
Rated current at 60°C

32.49 A
Rated current at 65°C

31.23 A
Rated current at 70°C

29.98 A
Rated short-circuit breaking capacity Icn under 400 V AC according to IEC 60898-1

10 kA
Rated service breaking capacity Ics AC according to IEC 60898-1

7.50 kA
Rated ultimate short-circuit breaking capacity Icu under 230 V AC IEC 60947-2

30 kA

Cross-section of input and output with screws, for massive conductors

1 - 35 mm²
Cross-section of input and output with screws, for flexible conductors

1 - 25 mm²
Cross-section of input with screws, for flexible conductors

1 - 25 mm²
Cross-section of input with screws, for massive conductors

1 - 35 mm²

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers catalog.pageproduct.product_description_learn_more.link

RoHS conform Yes
