125A 8 Way TPN Board Plain Door JK108B
EAN
5015652250272
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Transition cover section for installation duct 2 products available -
Distributor assembly with main switch 3 products available -
Distributor assembly for device surface mounting 1 products available -
Gland plate for enclosure 1 products available -
Component for earthing/equipotential bonding 1 products available
-
See more 19 other products available
Complete your system
Technical properties
Installation, mounting
-
Suitable for outdoor usageNo
-
Mounting onSurface mounting
Electric current
-
Rated current125 A
Equipment
-
With lockYes
-
Has neutral terminal blockYes
-
Has earthing terminal blockYes
Dimensions
-
Height625 mm
-
Width465 mm
-
Depth132.50 mm
Cover, door
-
Number of cabinet doors1
-
Door/cover is transparentNo
Materials
-
MaterialSteel
-
RAL code7035
-
ColourLight grey
Safety
-
Protection classIsolation class III
-
Impact resistance IKIK05
-
Ingress Protection (IP) classIP30
-
Locking typeKey lock, Quarter turn lock
