Dimmer 3 outputs KNX, 1/10V TX211A
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Voltage
-
Operating voltage over bus21 - 32 V
-
System supply voltage30 V DC Via bus
Frequency
-
Frequency50 - 50 Hz
Use conditions
-
Operating temperature0 - 45 °C
Connection
-
Cross-section flexible conductor1 - 6 mm²
-
Cross-section rigid conductor1.5 - 10 mm²
Equipment
-
Number of outputs3
-
Type of dimmer1 - 10 V
Capacity
-
Number of modules4
Power
-
230 V incandescent and halogen lamp2,300 W
-
Power of variator0 - 2,300 W
Connectivity
-
With bus system KNX radioNo
-
Type of connectionScrew terminal
Settings
-
Supported configuration modeETS
Texts
-
Type of connectionWith screw terminals
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet TX211A
Dimmer 3 outputs KNX, 1/10V
PDF -
Installation manual
Installation manual en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, nn-NO, pl-PL, pt-PT, sv-SE 2010-07-09
PDF2,60 MB -
KNX product database
Logiciel d'application ETS du TX211A
KNX product database da-DK, en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, pl-PL, pt-PT 2020-01-01
KNXPROD48,86 kB
Logiciel d'application ETS du TX211A
KNX product database da-DK, en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, pl-PL, pt-PT 2020-01-01
VD532,31 kB
