Fuse carrier 1P+N 50A 690V L51 accessoriability 3M LS612
EAN-Nr.
3250614196126
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Cylindrical fuse 25 products available -
Accessories/spare parts for low-voltage switch technology 2 products available
Complete your system
-
LF412GIndustrial fuse-links 14x51 gG 12A
-
LF445GIndustrial fuse-links 14x51 gG 45A
-
LF445MIndustrial fuse-links 14x51 aM 45A
-
LF402GIndustrial fuse-links 14x51 gG 2A
-
LF402MIndustrial fuse-links 14x51 aM 2A
-
LF404GIndustrial fuse-links 14x51 gG 4A
-
LF404MIndustrial fuse-links 14x51 aM 4A
-
LF406GIndustrial fuse-links 14x51 gG 6A
-
LF406MIndustrial fuse-links 14x51 aM 6A
-
LF408GIndustrial fuse-links 14x51 gG 8A
-
LF408MIndustrial fuse-links 14x51 aM 8A
-
LF410GIndustrial fuse-links 14x51 gG 10A
-
LF410MIndustrial fuse-links 14x51 aM 10A
-
LF450M
Industrial fuse-links 14x51 aM 50A
-
LF416GIndustrial fuse-links 14x51 gG 16A
-
LF416MIndustrial fuse-links 14x51 aM 16A
-
LF420GIndustrial fuse-links 14x51 gG 20A
-
LF420MIndustrial fuse-links 14x51 aM 20A
-
LF425GIndustrial fuse-links 14x51 gG 25A
-
LF425MIndustrial fuse-links 14x51 aM 25A
Technical characteristics
Dimensions
-
Height107 mm
-
Width52.50 mm
-
Depth93 mm
Architecture
-
Number of poles2
Electric current
-
Rated current50 A
-
Rated current of fuse cartridge2 A, 4 A, 6 A, 10 A, 12 A, 16 A, 20 A, 25 A, 32 A, 40 A, 50 A
Capacity
-
Number of modules3
Internal use only
-
Number of half modules of 17,5 mm6
Use conditions
-
Operating temperature-5 - 40 °C
Installation, mounting
-
Nominal tightening torque3.5 - 3.5 Nm
-
Mounting onDIN rail
Power
-
Total power loss under IN8.30 W
Voltage
-
Rated insulation voltage Ui690 V
-
Rated impulse withstand voltage Uimp8 kV
-
Type voltage supplyAC
-
Overvoltage category according to IEC 60947-13
Safety
-
Ingress Protection (IP) classIP20
Connection
-
Cross-section of input and output with screws, for flexible conductors16 - 16 mm²
-
Cross-section of input and output with screws, for massive conductors25 - 25 mm²
Fuse
-
Fuse size14 x 51
Cover, door
-
InterlockableYes
