Moulded Case Circuit Breaker h3 x160 TM FIX 4P4D 125A 40kA CTC HNA126Z

Name: HNA126Z
Brand: Hager
SKU: HNA126Z11

EAN-Nr.

3250613149727

Packaging

1 piece

Accessories
Technical characteristics
Environmental value
Documentations
More products

Download the sheet

Complete your system

DIN rail adapter 1 products available
Phase separation functions 1 products available
Locking interlocking functions 1 products available
Connection Functions 1 products available
Handle for power circuit breaker 2 products available
Under voltage coil 3 products available

Technical characteristics

Rated current

125 A
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-2

40 kA
Rated ultimate short-circuit breaking capacity Icu under 240 V AC IEC 60947-2

85 kA
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-2

40 kA
Rated service breaking capacity Ics under 400 V AC according to IEC 60947-2

20 kA
Rated current 10°C according to IEC 60947

148.80 A
Rated current 15°C according to IEC 60947

146 A
Rated current 20°C according to IEC 60947

143.20 A
Rated current 25°C according to IEC 60947

140.30 A
Rated current 30°C according to IEC 60947

137.40 A
Rated current at 35°C according to IEC 60947

134.40 A
Rated current at 40°C according to IEC 60947

131.30 A
Rated current 45°C according to IEC 60947

128.20 A
Rated current 50°C according to IEC 60947

125 A
Rated current 55°C according to IEC 60947

121.60 A
Rated current at 60°C according to IEC 60947

118.20 A
Rated current 65°C according to IEC 60947

114.70 A
Rated current 70°C according to IEC 60947

111.10 A

Number of poles

4

Response time when opening

10 ms

Frequency

50 - 60 Hz

Rated impulse withstand voltage Uimp

8,000 V
Rated insulation voltage Ui

690 V

Trip unit

TM F/F

Total power loss under IN

33 W

Electric endurance in number of cycles

10,000
Number of mechanical operations

20,000

Ingress Protection (IP) class

IP4X

Cross-section flexible conductor

4 - 70 mm²
Cross-section rigid conductor

4 - 95 mm²

Type of connection

Screw terminal

Thermal protection knob setting xIN

1, 1

Height

130 mm
Width

100 mm
Depth

68 mm

Suitable for DIN Rail

No

Magnetic protection trip time

0 - 0 ms

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes
