EAN-Nr.

4011334418689

Packaging

1 piece

Push-button module 1gang, bus coupling unit, KNX-W.1, light grey/grey gl./mat 80141200

Phase out product: please contact your electrical wholesaler for availability

Accessories
Technical characteristics
Environmental value
Documentations

Download the sheet

Complete your system

Must-have accessories

See all (13)

Surface-mounted lower casing 2gang horizontal, w. frame and cable entries W.1 pw

Frame 1gang for flush-mounted installation, with sealing, W.1, polar white

Frame 3g horizontal for flush-mounted installation, with sealing W.1p-w

Frame 2gang horizontal for flush-mounted installation, with sealing, W.1, p-w

Frame 2gang vertical for flush-mounted installation, with sealing, W.1, p-w

Frame 3g horizontal for flush-mounted installation, with sealing W.1light grey

Technical characteristics

Mounting on

Flush mounting, Surface mounting

Operating temperature

-40 - 30 °C

Bus current consumption data transfer

10 mA

With room temperature controller

No

Built-in depth

22 mm
Built-in depth flush-mounted boxes

32 mm
Height

44 mm
Width

45.70 mm
Depth

40.50 mm

Number of actuation points

1

With LED indication

Yes

Colour

Grey
RAL code

7035
Material

Duroplastic
Surface finish

Glossy, Matt

Has labelling field

No

With display

No

Function

Function for manual interruption of automatic functions already triggered

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

Certifications and documents

Hager REACH declaration 80141200

PDF

Hager RoHS report 80141200

PDF

Downloads

Product Image 80141200
Product datasheet

Hager Product data sheet 80141200

Push-button module 1gang, bus coupling unit, KNX-W.1, light grey/grey gl./mat

PDF
Installation manual

Installation manual en-GB, de-DE 2021-09-29

PDF

1,22 MB
Technical appendix (single product)

Splash-protected range W.1 - Chemical resistance (EN, 07-2021)

Technical appendix (single product) en-GB 2015-07-13

PDF

518,42 kB
KNX product database

ETS Database for 80141X00

KNX product database en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, nn-NO, pt-PT, sv-SE 2020-01-01

KNXPROD

616,06 kB
Application Guide

Application description ETS for 80141XXX - KNX W.1 push button-/group push button mpdule 1-/2gang with bcu (EN, 2016-12)

Application Guide en-GB 2022-02-22

PDF

2,32 MB
Declaration of conformity

Declaration of Conformity

Declaration of conformity International 2021-05-04

PDF

266,44 kB

Declaration of conformity International 2020-01-01

PDF

533,53 kB
