B.IQ push-button 4gang f. light scenes, KNX - B.IQ, stainl. steel, metal brushed 75168693

EAN-Nr.
4011334257233
Packaging
1 piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

B.IQ push-button 4gang f. light scenes, KNX - B.IQ, stainl. steel, metal brushed

75168693

  • Accessories
  • Technical characteristics
  • Environmental value
  • Documentations
  • More products
Download the sheet

Complete your system

Must-have accessories

Previous
Previous
75040001
75040001
Bus coupling unit flush-mtd, KNX
Add to a list
Add to a list

Optional accessories

  • Labelling material for domestic switching devices 1 products available

Complete your system

  • Labelling material for domestic switching devices
  • 75900081

    B.IQlab. field for push-buttons 4gang, B.IQ, clear, trans.
    0.00 €  / *

Technical characteristics

Installation, mounting
  • Mounting on
    Flush mounting
Use conditions
  • Operating temperature
    -5 - 45 °C
Functions
  • With room temperature controller
    No
Dimensions
  • Height
    118.10 mm
  • Width
    88.50 mm
  • Depth
    16.65 mm
Equipment
  • Number of actuation points
    8
Controls and indicators
  • With LED indication
    Yes
Materials
  • Colour
    Stainless steel
  • RAL code
    9022
  • Material
    Metal, Stainless steel
  • Surface finish
    Matt
Accessories
  • Has labelling field
    No
Screen
  • With display
    No
Texts
  • Protection
    With dismantling protection

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

REACh-SVHC free Yes

Certifications and documents

REACH declaration 75168693
PDF

Downloads

  • Image 75168693 | Hager

    Product Image 75168693

  • Product datasheet

    Image Hager Product data sheet 75168693 | Hager

    Hager Product data sheet 75168693

    B.IQ push-button 4gang f. light scenes, KNX - B.IQ, stainl. steel, metal brushed

    PDF

  • Installation manual

    Image Manual for 751686xx - B.IQ push-button 8gang for light scenes (DE-EN-NL-NO-ES, 2022-09) | Hager

    Manual for 751686xx - B.IQ push-button 8gang for light scenes (DE-EN-NL-NO-ES, 2022-09)

    Installation manual en-GB, es-ES, de-DE, nl-NL, nn-NO 2004-04-20

    PDF
    363,07 kB

  • KNX product database

    Image KNX Database (from ETS2) for 7516869xx - B.IQ push-button 4gang for light scenes (2012-10) | Hager

    KNX Database (from ETS2) for 7516869xx - B.IQ push-button 4gang for light scenes (2012-10)

    KNX product database International 2023-08-25

    VD1
    67,45 kB
    Image KNX Database (from ETS2) for 7516869xx - B.IQ push-button 4gang for light scenes (2012-10) | Hager

    KNX Database (from ETS2) for 7516869xx - B.IQ push-button 4gang for light scenes (2012-10)

    KNX product database International 2023-08-25

    VD1
    161,95 kB

  • Application Guide

    Image Application description ETS for 7516869xx - B.IQ push-button 4gang for light scenes (EN, 2004-08) | Hager

    Application description ETS for 7516869xx - B.IQ push-button 4gang for light scenes (EN, 2004-08)

    Application Guide en-GB 2020-01-01

    PDF
    151,37 kB
