SKO-STD M AMBEL SRBKL K.X ANTH HGL • 41097006 | Hager
Middle-East
Menu
Account

SCHUKO soc.out. LEDorient.,enhncd contact prot.,screw-in lift term.,K1,ant.,lacq 41097006

EAN-Nr.
4011334365822
Packaging
10 Pieces

Complete your system

Optional accessories

  • Cover frame for domestic switching devices 7 products available

Compatible products

  • Referenced by 21 products available

Technical characteristics

Voltage
  • Rated voltage
    250 V
Electric current
  • Rated current
    16 A
Frequency
  • Frequency
    50 - 60 Hz
Materials
  • Colour
    Anthracite
  • RAL code
    7021
  • Surface finish
    Matt
  • Material
    Thermoplastic
  • Treatment
    Untreated, Varnished
Dimensions
  • Height
    71 mm
  • Width
    71 mm
  • Number of units
    1
  • Built-in depth
    32 mm
Installation, mounting
  • Mounting on
    Flush mounting
Connectivity
  • Type of connection
    Screw terminal
  • Mounting type
    Screw mounting, Claw mounting
Equipment
  • Connector/plug type socket outlet
    SCHUKO
  • Rotated central insert
    No
  • With hinged lid
    No
  • With round protective earth pin
    No
  • With signal lamp
    No
  • With lock
    No
Accessories
  • Has labelling field
    No
Capacity
  • Number of modules
    1
Controls and indicators
  • Type of lighting for the installation devices
    Integrated orientation light
Safety
  • With enhanced contact protection
    Yes
  • Impact resistance IK
    IK05
  • Ingress Protection (IP) class
    IP20
Functions
  • With orientation lighting
    Yes
  • With function lighting
    No
Identification
  • With imprint
    No
  • Related Systems
    K.x

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

Certifications and documents

Socket-outlet 2-gang Wago plug/clamp technique C-Profile in traffic white
PDF
48,73 MB
Hager REACH declaration 41097006
PDF
Hager RoHS report 41097006
PDF
