    • VB318R
    EAN
    3250611019749
    Packaging
    1 Piece

    Small distributor,vega,surface,3row,54M,IP40,QC-terminal,PE,transparent door VB318R

    Phase out product: please contact your electrical wholesaler for availability

    Follow-up products :

    VB318B

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in

    Small distributor,vega,surface,3row,54M,IP40,QC-terminal,PE,transparent door

    VB318R

    • Accessories
    • Technical properties
    • Environmental value
    • Documentations

    Complete your system

    Optional accessories

    • Common Accessories 1 products available
    • Cable guide for enclos­ures/cab­inets 2 products available
    • Cable entry 1 products available
    • Cleaning product 1 products available
    • Coax connector 1 products available

    Complete your system

    • Common Accessories
    • Cable guide for enclos­ures/cab­inets
    • Cable entry
    • Cleaning product
    • Coax connector
    • VZ041VB

      IP41 kit, vega, slider with load attachment plate, roof, seal, RAL9010
      €0.00  / *
    • VZ014VB

      Trunking Kit, vega, 25x60mm, horizontal, 1 to 4 row
      €0.00  / *
    • VZ012VB

      Trunking Kit, vega, 25x60mm, 3row, vertical
      €0.00  / *
    • VZ001VB

      Slider, vega, for trunking inlet, max. section 90x300mm
      €0.00  / *
    • VZ404

      Cleaning spray, volta, for plastic surfaces
      €0.00  / *
    • TN010S

      Coax Modul F/F
      €0.00  / *

    Technical properties

    Install­a­tion, mounting
    • Suit­able for outdoor usage
      No
    • Mounting on
      Surface mounting
    Elec­tric current
    • Rated current IN
      125 A
    Equip­ment
    • Number of rails
      3
    • Number of rows
      3
    • With lock
      No
    • Has neutral terminal block
      No
    • Has earthing terminal block
      Yes
    • Has mounting plate
      No
    Capa­city
    • Number of modules
      54
    Dimen­sions
    • Height
      625 mm
    • Width
      400 mm
    • Depth
      146 mm
    • Number of width units
      18
    Cover, door
    • Number of cabinet doors
      1
    • Number of locks
      1
    • Door/­cover is trans­parent
      Yes
    • Cabinet door type
      Single door
    Connectivity
    • Mounting type
      Surface mounting
    Mater­ials
    • Material
      Poly­styrene (PS)
    • RAL code
      9010
    • Colour
      White
    Safety
    • Protec­tion class
      Isol­a­tion class II
    • Impact resist­ance IK
      IK07
    • Ingress Protec­tion (IP) class
      IP40
    • Locking type
      Snap on lock, Without lock
    • Glow wire test
      650 °C
    • Protec­tion class with door
      IP40

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

    Certifications and documents

    PEP - ENCLOSURE SURFACE GAMMA 26 M (english)
    PDF
    25,39 MB

    Downloads

    • Image VB318R | Hager Africa

      Product Image VB318R

    • Installation manual

      Image Installation manual en-GB, fr-FR, de-DE, nl-NL 2026-09-03 | Hager Africa

      Installation manual en-GB, fr-FR, de-DE, nl-NL 2026-09-03

      PDF
      15,97 MB

    • Product certificate

      Image Product certificate International 2024-03-19 | Hager Africa

      Product certificate International 2024-03-19

      PDF
      3,01 MB
      Image Product certificate en-GB, fr-FR 2019-01-16 | Hager Africa

      Product certificate en-GB, fr-FR 2019-01-16

      PDF
      925,70 kB
      Image Product certificate en-GB, fr-FR 2019-01-16 | Hager Africa

      Product certificate en-GB, fr-FR 2019-01-16

      PDF
      931,80 kB

    • Declaration of conformity

      Image Declaration of conformity International 2023-09-13 | Hager Africa

      Declaration of conformity International 2023-09-13

      PDF
      321,32 kB
      Image Declaration of conformity en-GB 2026-07-22 | Hager Africa

      Declaration of conformity en-GB 2026-07-22

      PDF
      472,58 kB
