The Hager internal corner, halogen‑free, for LF/LFF 40x90 trunking in stone grey (RAL7030) provides a neat, safe inside-corner transition. Moulded ABS with IK07 impact resistance and overlapping design ensures robust, concealed routing. Adjustable 83-97° for uneven walls, click mounting for quick install. Size 40×90 mm (a=115 mm). Operates -5 to 60 °C. Ideal for residential and commercial trunking runs.

EAN

4012740022583

Packaging

1 Piece

Internal Corner 90° Halogen Free for Trunking 60x150mm Stone Grey IK07 LFF4009047030

Technical properties
Environmental value
Documentations
More products

Download the data sheet

Technical properties

Type of accessory

Moulded

Angle range

83 - 97

Height

40 mm
Width

90 mm
Measurement a

115 mm

Material

Acrylonitrile-Butadiene-Styrene (ABS)
Treatment

Untreated
Colour

Stone grey
RAL code

7030

Impact resistance IK

IK07

Suitable for functional integrity according to DIN4102-12

No

Operating temperature

-5 - 60 °C

With protective film

No

Overlapping

Yes

Mounting type

Click mounting

Related Series

LFF 40x90

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes

Halogen free Yes
