The Hager Automatic Transfer Switch 4x 630A ensures seamless source changeover for critical three-phase installations. Rated 630 A at 380-415 V with 414 kW (AC1 at 400 V), it delivers high reliability and continuity of service. With 4 poles and 50 kA Icc (gl/gG fuses), it offers robust fault withstand. Fixed built-in for distribution boards, mounted on a plate—ideal for industrial and commercial power backup systems.
EAN
3250613131838
Packaging
1 Piece
ATS 4P 400A 380-415V 50kA with energy management HIC463G
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Accessories/spare parts for low-voltage switch technology 2 products available -
Terminal cover 1 products available
Technical properties
Voltage
-
Rated operational voltage Ue380 - 415 V
Electric current
-
Rated current630 A
-
Rated conditional short-circuit current Icc with gl-gG fuses50 kA
Power
-
Rated operational power under 400 V AC AC1414000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Installation, mounting
-
Mounting onMounting plate
