The Hager motorized transfer switch 4P 1000A ensures automatic, reliable source changeover for large three-phase systems, isolating all poles including neutral. Rated 1000A at 380-415V with 50kA conditional short-circuit withstand (gl/gG), it handles up to 658 kW at 400V AC1. Fixed built-in design for distribution boards, plate-mounted. Ideal for mains-generator continuity and remote control.
EAN
3250613191412
VPE
1 piece
Motorized transfer switch 4P 250A 50kA 415V Fixed built-in, mounting plate HIB490M
catalog.lists.product_addition.login_popup.title
catalog.lists.product_addition.login_popup.descriptive_text
product.page.accessories.title
product.page.accessories.associated-products
-
Accessories/spare parts for low-voltage switch technology 3 product.page.accessories.products-available -
Controller for automatic transfer switch 1 product.page.accessories.products-available
product.page.accessories.compatible.title
-
product.page.accessories.referenced_by.title 1 product.page.accessories.products-available
product.page.accessories.referenced_by.title
Technical characteristics
Voltage
-
Rated operational voltage Ue380 - 415 V
Electric current
-
Rated current IN1000 A
-
Rated conditional short-circuit current Icc with gl-gG fuses50 kA
Power
-
Rated operational power under 400 V AC AC1658000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Installation, mounting
-
Mounting onMounting plate
