The Hager K.5 stainless steel 1-gang KNX push-button with RGB LED and integrated temperature sensor delivers room control, status feedback, and scene activation. Two actuation points with manual override of automations, label field, and dismantling protection. Works as a room thermostat/controller extension via KNX objects. Flush-mounted, matte RAL9022, 20 mA bus draw, -5…45°C. Compact: 55.1×70.9×14.35 mm.
EAN
3250617153478
Packaging
1 Piece
KNX Push-button 2-gang with temp sensor and integrated bus coupler K.1 80161773
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Must-have accessories
Compatible products
-
Referenced by 1 products available
Technical properties
Installation, mounting
-
Mounting onFlush mounting
Use conditions
-
Operating temperature-5 - 45 °C
Electric current
-
Bus current consumption data transfer20 mA
Functions
-
With room temperature controllerYes
Dimensions
-
Height55.10 mm
-
Width70.90 mm
-
Depth14.35 mm
Equipment
-
Number of actuation points2
Controls and indicators
-
With LED indicationYes
Materials
-
ColourStainless steel
-
RAL code9022
-
MaterialStainless steel, Thermoplastic
-
Surface finishMatt
Accessories
-
Has labelling fieldYes
Screen
-
With displayNo
Texts
-
FunctionFunction for manual interruption of automatic functions already triggered
-
ProtectionWith dismantling protection
-
TemperatureIntegrated temperature sensor with output of the measured values via object, Integrated temperature sensor for operation as controller extension unit
Scope of delivery
-
Bus connection includedNo
