MCB 2P 10kA/15kA C-2A 2M NCN202A
EAN
3250614615610
Packaging
6 Pieces
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Mechanic accessories for low-voltage components 1 products available -
Auxiliaries contact block 2 products available -
Shunt release 1 products available -
Under voltage coil 1 products available -
Phase separation functions 1 products available -
See more 4 other products available
Complete your system
Technical properties
Electric current
-
Rated current2 A
-
Rated ultimate short-circuit breaking capacity Icu under 230 V AC IEC 60947-230 kA
-
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-215 kA
-
Rated current -25°C2.67 A
-
Rated current at -20°C2.62 A
-
Rated current -15°C2.56 A
-
Rated current -10°C2.51 A
-
Rated current -5°C2.45 A
-
Rated current at 0°C2.39 A
-
Rated current 5°C2.33 A
-
Rated current 10°C2.27 A
-
Rated current 15°C2.20 A
-
Rated current at 20°C2.14 A
-
Rated current 25°C2.07 A
-
Rated current 30°C2 A
-
Rated current 35°C1.93 A
-
Rated current at 40°C1.85 A
-
Rated current at 45°C1.77 A
-
Rated current at 50°C1.69 A
-
Rated current 55°C1.60 A
-
Rated current 60°C1.51 A
-
Rated current 65°C1.41 A
-
Rated current 70°C1.31 A
Architecture
-
Type of pole2P
-
CurveC
Capacity
-
Number of modules2
Installation, mounting
-
Nominal tightening torque top terminal2.80 - 2.80 Nm
-
Nominal tightening torque down terminal2.80 - 2.80 Nm
-
Nominal tightening torque2.80 - 2.80 Nm
-
Type of bottom connection for modular devicesbiconnect
-
Type of top connection for modular devicesScrew terminal
-
360° mounting position possibleYes
Main electrical attributes
-
Rated short-circuit breaking capacity Icn AC according to IEC 60898-110 kA
Voltage
-
Rated operational voltage Ue400 - 400 V
-
Type voltage supplyAC
-
Rated insulation voltage Ui500 V
-
Rated impulse withstand voltage Uimp6,000 V
Frequency
-
Frequency50 - 60 Hz
Connection
-
Cross-section of input and output with screws, for massive conductors1 - 35 mm²
-
Cross-section of input and output with screws, for flexible conductors1 - 25 mm²
-
Cross-section of input with screws, for flexible conductors1 - 25 mm²
-
Cross-section of input with screws, for massive conductors1 - 35 mm²
Safety
-
Ingress Protection (IP) classIP20
Use conditions
-
Degree of pollution according to IEC 60664 / IEC 60947-22
-
Class of energy limitation I²t3
-
Operating temperature-25 - 70 °C
Power
-
Total power loss under IN4.10 W
Endurance
-
Electric endurance in number of cycles4,000
-
Number of mechanical operations20,000
Connectivity
-
Type of connectionScrew terminal
-
Top connection alignment for modular devicesAligned terminal
-
Down connection alignment for modular devicesAligned terminal
Dimensions
-
Height83 mm
-
Width35 mm
-
Depth70 mm
