Steel enclosure, Univers, IP55, CL1, 1700x1050x275 mm, plinth H200 mm FR14E2

EAN
3250610700907
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Steel enclosure, Univers, IP55, CL1, 1700x1050x275 mm, plinth H200 mm

FR14E2

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • See more (36)
    • Lock system 8 products available
    • Cable gland 1 products available
    • Hinge for distri­bu­tion systems 1 products available
    • Accessor­ies/s­pare parts for earthing and light­ning 1 products available
    • Docu­ment holder 6 products available
    • Compon­ents for wiring, cable entry and cable fixing 4 products available

    Complete your system

    • Lock system
    • Cable gland
    • Hinge for distri­bu­tion systems
    • Accessor­ies/s­pare parts for earthing and light­ning
    • Docu­ment holder
    • Compon­ents for wiring, cable entry and cable fixing
    • Base/­base element
    • Gland plate for enclosure
    • Touch-up stick
    • Insert for lock system
    • Compon­ents for arrange­ment/baying system
    • Compon­ents for door
    • Mounting accessories
    • Top panel/roof for enclosure
    • Trans­port accessories
    • Door/­op­er­ating panel
    • DIN rail
    • FZ537

      Rotary and sealing handle lock, Univers

      0.00 €  / *
    • FZ520

      Euro-profile cylinder 455 for swing lever FZ537

      0.00 €  / *
    • FZ519

      Euro-profile cylinder 405 for swing lever FZ537

      0.00 €  / *
    • FZ506

      Euro-profile cylinder 1242E for swing lever FZ537

      0.00 €  / *
    • FZ530

      Lock, univers, T-handle, for enclosures FA / FT / FG

      0.00 €  / *
    • MES-PHZ4K8

      Profile half cylinder square 8mm

      0.00 €  / *
    • MES-PHZ3K7

      Profile half cylinder triangular 7mm

      0.00 €  / *
    • MES-PHZDB3

      Profile half cylinder double-bit 3mm

      0.00 €  / *
    • VZ020M

      Cable gland, vector, IP65, M20, plastic

      0.00 €  / *
    • FZ797A

      Hinge pins, Univers, D5x74 mm

      0.00 €  / *
    • UZ009

      PE cable, universN, 25mm², 300mm, both cable shoe 6mm / 8mm

      0.00 €  / *
    • FZ794

      Document holder, transparent, DIN A4, adhesive

      0.00 €  / *
    • FZ757M

      Document holder, magnetic, DIN A4

      0.00 €  / *
    • FZ757A5

      Document holder, adhesive, DIN A5

      0.00 €  / *
    • FZ757A4

      Document holder, glued, DIN A4

      0.00 €  / *
    • FZ818

      Document holder, plastic, DIN A4, adhesive

      0.00 €  / *
    • FZ710

      Document holder, Univers

      0.00 €  / *
    • FZ774A

      Adapter for vertical connection of 1050mm wide FR/FS enclosures

      0.00 €  / *
    • FZ8441

      Cable rail, IP54, fixing on plinth, Univers, 4 sections L980 mm

      0.00 €  / *
    • FZ800A

      Adjustable rail holder CL1, Univers, for strain relief rail D275 mm

      0.00 €  / *
    • UT21D

      Strain relief rail, Univers, for additional support of uprights L1000 mm

      0.00 €  / *
    • FZ634A

      Plinth, Univers, H100 1050x275 mm

      0.00 €  / *
    • FZ644A

      Plinth, Univers, H200 1050x275 mm

      0.00 €  / *
    • FZ422

      Metal cable entry plate CL1, Univers, IP55 230x120 mm

      0.00 €  / *
    • FZ435A

      Cover plate, univers, to close cable entry openings in FR enclousures

      0.00 €  / *
    • MES-LSTI7035

      Touch-up stick prepared 12ml RAL7035

      0.00 €  / *
    • FZ537PB

      Push Button Insert for sealing handle lock univers FZ537

      0.00 €  / *
    • FZ801B

      Holder, Univers, strain relief rail H200 mm fixing on plinth

      0.00 €  / *
    • FZ739B

      Door wiring profile, Univers, H500 mm

      0.00 €  / *
    • FZ829

      Wall fixation lugs, Univers

      0.00 €  / *
    • FZ721B

      Horizontal coupling kit, Univers, L400 mm

      0.00 €  / *
    • FZ230A

      Upright support, Univers, D275 mm

      0.00 €  / *
    • FZ831

      Crane rings, Univers, M8 thread, 140 kg per ring

      0.00 €  / *
    • FZ014R

      Door, Univers, IP55, H1700 W1050 mm

      0.00 €  / *
    • U82A

      DIN rail, univers, 7, 5 mm, depth-adjustable until 32, 5mm, 11 modules wide (200mm)

      0.00 €  / *
    • UN11A

      Carrier rails, univers, for enclosures ex depth = 160mm, L = 1650mm, 2 pieces

      0.00 €  / *

    Technical properties

    Dimen­sions
    • Height
      1,900 mm
    • Width
      1,050 mm
    • Depth
      275 mm
    • Thick­ness of side­wall
      1.50 mm
    Safety
    • Ingress Protec­tion (IP) class
      IP55
    • Protec­tion class
      Isol­a­tion class I
    • Locking type
      Without lock
    • Impact resist­ance IK
      IK10
    Equip­ment
    • Number of section in width
      4
    • Number of flange plate open­ings
      8
    • Number of rows
      11
    Install­a­tion, mounting
    • Mounting on
      Floor mounting
    • Suit­able for outdoor usage
      No
    Mater­ials
    • Colour
      Light grey
    • RAL code
      7035
    • Treat­ment
      Powder coated
    • Material
      Steel
    • Surface finish
      Matt
    Cover, door
    • Number of cabinet doors
      2
    • Number of locks
      1
    • Door/­cover is trans­parent
      No
    Elec­tric current
    • Rated current
      800 A
    Voltage
    • Nominal voltage
      690 - 690 V

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

    RoHS conform Yes

    Certifications and documents

    FWB enclosure,UNIVERS range, 5-rows 180 modules
    PDF
    49,47 MB
    Hager REACH declaration FR14E2
    PDF
    Hager RoHS report FR14E2
    PDF

    Downloads

    • Product image

      Image FR14E2  | Hager

      Product Image FR14E2

    • Product datasheet

      Image Hager Product data sheet FR14E2  | Hager

      Hager Product data sheet FR14E2

      Steel enclosure, Univers, IP55, CL1, 1700x1050x275 mm, plinth H200 mm

      PDF
    • Declaration of conformity

      Image EU Declaration of Conformity  | Hager

      EU Declaration of Conformity

      Declaration of conformity en-GB 2025-03-14

      PDF
      684,89 kB
      Image EU Declaration of Conformity  | Hager

      EU Declaration of Conformity

      Declaration of conformity en-GB 2025-03-14

      PDF
      717,48 kB
