    EAN-Nr.
    3250618502497
    Packaging
    1 piece

    Gateway KNX-DALI 2, tunable white, 4 modules TYA670WD2

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in
    Phase out product: please contact your electrical wholesaler for availability

    Gateway KNX-DALI 2, tunable white, 4 modules

    TYA670WD2

    • Technical characteristics
    • Environmental value
    • Documentations
    Download the sheet

    Technical characteristics

    Equipment
    • Web server
      Yes
    • Number of channels
      1
    Voltage
    • Operating voltage
      240 - 240 V
    • Operating voltage over bus
      21 - 32 V
    • Type voltage supply
      DC
    Connectivity
    • Type of interface bus system/media gateway
      Light system interface/DALI
    Settings
    • Supported configuration mode
      ETS
    Power
    • Power consumption VA
      0.15 VA
    Safety
    • Ingress Protection (IP) class
      IP20
    Use conditions
    • Operating temperature
      5 - 45 °C
    Controls and indicators
    • With LED indication
      Yes
    Dimensions
    • Width
      72 mm
    • Depth
      70 mm
    • Number of width units
      4
    Connection
    • Connector/plug type
      DRA (DIN-rail Adapter)
    Texts
    • Voltage
      As DALI master and power supply for DALI devices
    • Type of connection
      With screw terminals

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    Hager REACH declaration TYA670WD2
    PDF
    Hager RoHS report TYA670WD2
    PDF

    Downloads

    • Image TYA670WD2 | Hager

      Product Image TYA670WD2

    • Product datasheet

      Image Hager Product data sheet TYA670WD2 | Hager

      Hager Product data sheet TYA670WD2

      Gateway KNX-DALI 2, tunable white, 4 modules

      PDF

    • Installation manual

      Image Installation manual en-GB, nl-NL 2021-02-23 | Hager

      Installation manual en-GB, nl-NL 2021-02-23

      PDF
      1,98 MB

    • KNX product database

      Image ETS Database for TYA670W / TYA670WD2 | Hager

      ETS Database for TYA670W / TYA670WD2

      KNX product database fr-FR 2020-01-01

      KNXPROD
      9,43 MB
      Image ETS Database for TYA670W / TYA670WD2 | Hager

      ETS Database for TYA670W / TYA670WD2

      KNX product database fr-FR 2020-01-01

      VD5
      10,72 MB
      Image ETS Database for TYA670W / TYA670WD2 | Hager

      ETS Database for TYA670W / TYA670WD2

      KNX product database en-GB 2020-01-01

      KNXPROD
      6,10 MB
      Image ETS Database for TYA670W / TYA670WD2 | Hager

      ETS Database for TYA670W / TYA670WD2

      KNX product database de-DE 2020-01-01

      KNXPROD
      6,15 MB
      Image ETS Database for TYA670W / TYA670WD2 | Hager

      ETS Database for TYA670W / TYA670WD2

      KNX product database en-GB 2020-01-01

      VD5
      6,82 MB
      Image ETS Database for TYA670W / TYA670WD2 | Hager

      ETS Database for TYA670W / TYA670WD2

      KNX product database de-DE 2020-01-01

      VD5
      6,93 MB

    • Application Guide

      Image Application description TYA670WD2 | Hager

      Application description TYA670WD2

      Application Guide en-GB 2018-07-12

      PDF
      3,71 MB

    • Declaration of conformity

      Image Declaration | Hager

      Declaration

      Declaration of conformity International 2022-03-29

      PDF
      125,46 kB
      Image Declaration | Hager

      Declaration

      Declaration of conformity International 2022-03-10

      PDF
      117,71 kB
