    • Home
    • Catalogue
    • SM102E
    EAN-Nr.
    3250615639998
    Packaging
    1 piece

    Multi-function measurement device SM102E

    Add to a list
    Add to a list

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in

    Multi-function measurement device

    SM102E

    • Technical characteristics
    • Environmental value
    • Documentations
    Download the sheet

    Technical characteristics

    Frequency
    • Frequency
      50 - 60 Hz
    Dimensions
    • Height
      96 mm
    • Width
      96 mm
    • Depth
      60 mm
    Capacity
    • Number of modules
      5
    Use conditions
    • Operating temperature
      -10 - 55 °C
    • Storage/transport temperature
      -20 - 80 °C
    Connectivity
    • Type of connection
      Screw terminal
    Connection
    • Cross-section flexible conductor
      2.5 - 6 mm²
    • Cross-section rigid conductor
      2.5 - 6 mm²
    Power
    • Total power loss under IN
      10 W
    • Power consumption VA
      10 VA
    Equipment
    • Type of display
      LCD
    Measurement
    • Frequency measuring range
      45 - 65 Hz
    • Type of measuring instrument
      Multimeter
    • Current measurement range
      0 - 9,999 A
    Installation, mounting
    • Mounting on
      Flush mounting, Surface mounting

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    Hager REACH declaration SM102E
    PDF
    Hager RoHS report SM102E
    PDF

    Downloads

    • Image SM102E | Hager

      Product Image SM102E

    • Product datasheet

      Image Hager Product data sheet SM102E | Hager

      Hager Product data sheet SM102E

      Multi-function measurement device

      PDF

    • Installation manual

      Image Notice SM102E FR-DE-GB-IT-NL-ES-PT | Hager

      Notice SM102E FR-DE-GB-IT-NL-ES-PT

      Installation manual en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, pt-PT 2011-09-21

      PDF
      4,12 MB
