Moulded Case Circuit Breaker h3 x160 TM FIX 1P1D 80A 18kA CTC HDA078Z

Name: HDA078Z
Brand: Hager
SKU: HDA078Z20

EAN-Nr.

3250613135911

Packaging

1 piece

Technical characteristics
Environmental value
Documentations
More products

Download the sheet

Technical characteristics

Rated current

80 A
Rated ultimate short-circuit breaking capacity Icu under 240 V AC IEC 60947-2

18 kA
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-2

18 kA
Rated current 10°C according to IEC 60947

106.90 A
Rated current 15°C according to IEC 60947

103.90 A
Rated current 20°C according to IEC 60947

100.90 A
Rated current 25°C according to IEC 60947

97.70 A
Rated current 30°C according to IEC 60947

94.40 A
Rated current at 35°C according to IEC 60947

91 A
Rated current at 40°C according to IEC 60947

87.50 A
Rated current 45°C according to IEC 60947

83.80 A
Rated current 50°C according to IEC 60947

80 A
Rated current 55°C according to IEC 60947

75.90 A
Rated current at 60°C according to IEC 60947

71.60 A
Rated current 65°C according to IEC 60947

67.10 A
Rated current 70°C according to IEC 60947

62.20 A

Number of poles

1
Control/operation element

Toggle
Device construction type

Fixed built-in
Neutral position

Without neutral

Response time when opening

10 ms

Frequency

50 - 60 Hz

Rated impulse withstand voltage Uimp

8,000 V
Rated insulation voltage Ui

690 V

Trip unit

TM F/F

Total power loss under IN

4.80 W

Electric endurance in number of cycles

10,000
Number of mechanical operations

20,000

Ingress Protection (IP) class

IP4X

Cross-section flexible conductor

4 - 70 mm²
Cross-section rigid conductor

4 - 95 mm²

Type of connection

Screw terminal

Thermal protection knob setting xIN

1, 1

Height

130 mm
Width

25 mm
Depth

68 mm

Suitable for DIN Rail

Yes

Mounting-/Connection Position

Front

Magnetic protection trip time

0 - 0 ms

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes
