    • Home
    • Catalogue
    • Distribution boards
    • DR and VegaD boards
    • vega D
    • FU22DN
    EAN-Nr.
    3250612710713
    Packaging
    1 piece
    • vega D

    Enclosure, NewVegaD, 537x550x150mm, 48 modules, flush-mounted, distribution FU22DN

    Add to a list
    Add to a list

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in

    Enclosure, NewVegaD, 537x550x150mm, 48 modules, flush-mounted, distribution

    FU22DN

    • Accessories
    • Technical characteristics
    • Environmental value
    • Documentations
    • More products
    Download the sheet

    Complete your system

    Optional accessories

    • Door/operating panel 2 products available
    • Mounting accessories 1 products available

    Complete your system

    • Door/operating panel
    • Mounting accessories
    • FD22TN

      Glazed door, NewVegaD, 400x500mm, for 2-rows enclosure
      0.00 €  / *
    • FD22PN

      Plain door, NewVegaD, 400x500mm, for 2-rows enclosure
      0.00 €  / *
    • ZZ42BS

      Kit with 4 plastic screws for frame mounting of VegaD/NewVegaD
      0.00 €  / *

    Technical characteristics

    Connection
    • Number of conduit inlets
      4
    Installation, mounting
    • Suitable for outdoor usage
      No
    • Mounting on
      Flush mounting
    Electric current
    • Rated current
      160 A
    Equipment
    • Number of rails
      2
    • Number of rows
      2
    • Number of section in width
      2
    • With lock
      No
    • Has neutral terminal block
      No
    • Has earthing terminal block
      No
    • Has mounting plate
      No
    Capacity
    • Number of modules
      48
    Dimensions
    • Height
      537 mm
    • Width
      600 mm
    • Depth
      150 mm
    • Built-in width
      550 mm
    • Built-in depth
      110 mm
    • Number of width units
      24
    Cover, door
    • Door/cover is transparent
      No
    Materials
    • Material
      Metal, Plastic
    • RAL code
      9010
    • Colour
      Pure white
    Safety
    • Protection class
      Isolation class II
    • Impact resistance IK
      IK07
    • Ingress Protection (IP) class
      IP30
    • Locking type
      Without lock

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

    RoHS conform Yes

    Certifications and documents

    Encl., NewVegaD, 900x550x193mm, 120 mod.
    PDF
    472,28 kB
    Hager REACH declaration FU22DN
    PDF
    Hager RoHS report FU22DN
    PDF

    Downloads

    • Image FU22DN | Hager

      Product Image FU22DN

    • Product datasheet

      Image Hager Product data sheet FU22DN | Hager

      Hager Product data sheet FU22DN

      Enclosure, NewVegaD, 537x550x150mm, 48 modules, flush-mounted, distribution

      PDF

    • Installation manual

      Image Installation manual International 2020-01-01 | Hager

      Installation manual International 2020-01-01

      PDF
      11,99 MB

    • Handbook

      Image Handbook en-GB 2023-07-07 | Hager

      Handbook en-GB 2023-07-07

      PDF
      11,76 MB
      Image Handbook fr-FR 2023-09-11 | Hager

      Handbook fr-FR 2023-09-11

      PDF
      11,49 MB

    • Declaration of conformity

      Image Declaration | Hager

      Declaration

      Declaration of conformity International 2022-10-11

      PDF
      190,72 kB
    More documentation

    Discover our other products of this range

      5
    • 1
      FD62PN - Plain door, NewVegaD, 1000x500mm, for 6-rows enclosure
      FD62PN
      Plain door, NewVegaD, 1000x500mm, for 6-rows enclosure
    • 2
      FD42TN - Glazed door, NewVegaD, 700x500mm, for 4-rows enclosure
      FD42TN
      Glazed door, NewVegaD, 700x500mm, for 4-rows enclosure
    • 3
      FD42PN - Plain door, NewVegaD, 700x500mm, for 4-rows enclosure
      FD42PN
      Plain door, NewVegaD, 700x500mm, for 4-rows enclosure
    • 4
      FU32DN - Enclosure, NewVegaD, 687x550x150mm, 72 modules, flush-mounted, distribution
      FU32DN
      Enclosure, NewVegaD, 687x550x150mm, 72 modules, flush-mounted, distribution
    • 5
      FD52TN - Glazed door, NewVegaD, 850x500mm, for 5-rows enclosure
      FD52TN
      Glazed door, NewVegaD, 850x500mm, for 5-rows enclosure
