    Delay on Timer EZN001

    Phase out product: please contact your electrical wholesaler for availability

    Technical characteristics

    Frequency
    • Frequency
      50 - 60 Hz
    Power
    • Power consumption during operation
      1.20 VA
    • Power loss at full load
      2 W
    • 230 V incandescent and halogen lamp
      450 W
    Use conditions
    • Operating temperature
      -20 - 50 °C
    • Storage/transport temperature
      -40 - 70 °C
    Connection
    • Cross-section flexible conductor
      1 - 6 mm²
    • Cross-section rigid conductor
      1.5 - 10 mm²
    • Number of contacts
      1
    • Type of contacts
      1x changeover
    Capacity
    • Number of modules
      1
    Texts
    • Switch mode
      Change-over contact, usable as NC or NO
    • Function
      Functions: On delay, off delay, single shot leading edge/single shot trailing edge, pulse shaping, flashing symmetrically, contact open/closed
    • Type of connection
      With screw terminals
    • Installation mode
      For mounting on DIN rail
    Dimensions
    • Height
      85 mm
    • Width
      17.50 mm
    • Depth
      58 mm
    Electric current
    • Acceptable current rating AC1
      8 A
    Equipment
    • Number of NC contacts
      0
    • Number of NO contacts
      0
    • Switch off delay
      Yes
    • Switch on delay
      No
    Settings
    • Time delay
      0.1 S - 10 h
    Voltage
    • Type voltage supply
      AC/DC
