Remote control dimmer 1-10V EV106
EAN-Nr.
3250612421060
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Voltage
-
Operating voltage230 - 230 V
Frequency
-
Frequency50 - 50 Hz
Connectivity
-
Dimming DALINo
Power
-
Power consumption during operation3 VA
-
Power consumption standby1 W
Use conditions
-
Operating temperature-10 - 45 °C
Dimensions
-
Height85 mm
-
Width71 mm
-
Depth65 mm
Connection
-
Cross-section rigid conductor1.5 - 10 mm²
-
Cross-section flexible conductor1 - 6 mm²
Capacity
-
Number of modules4
Electric current
-
Control current 1-10 V slave50 mA
Materials
-
ColourGrey
Texts
-
Type of connectionWith screw terminals
-
Installation modeFor mounting on DIN rail
-
JunctionConnection for illuminated (max. 5 mA) or standard push-buttons
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet EV106
Remote control dimmer 1-10V
PDF -
Installation manual
Installation manual en-GB, fr-FR, de-DE, nl-NL 2009-11-12
PDF2,72 MB
