EAN-Nr.

3250612421022

Packaging

1 piece

Universal remote control dimmer 1000W + display EV102

No longer available

Follow-up products :

EVN004

Technical characteristics
Documentations

Download the sheet

Technical characteristics

Rated operational voltage Ue

230 - 230 V

Frequency

50 - 50 Hz

Colour

Grey
RAL code

7035

Height

85 mm
Width

88.50 mm
Depth

65 mm

Power consumption during operation

15 VA
Power consumption standby

3 W
Power incandescent lamp

20 - 1,000 W

Operating temperature

-10 - 45 °C

Cross-section rigid conductor

1.5 - 10 mm²
Cross-section flexible conductor

1 - 16 mm²

Number of modules

5

Dimming principle

Automatic load detection
Installation mode

For mounting on DIN rail
Type of connection

With screw terminals
Junction

Connection for illuminated (max. 5 mA) or standard push-buttons

Substation input

Yes

Downloads

Product Image EV102
Product datasheet

Hager Product data sheet EV102

Universal remote control dimmer 1000W + display

PDF
Installation manual

Annexe de parametrage pour televariateurs EV 102 et EV 108

Installation manual en-GB, es-ES, fr-FR, de-DE, nl-NL, nn-NO, pt-PT, sv-SE 2020-01-01

PDF

2,40 MB

Installation manual en-GB, fr-FR, de-DE, nl-NL 2017-09-11

PDF

1,59 MB
Declaration of conformity

Declaration

Declaration of conformity International 2020-02-07

PDF

108,61 kB
