Latching relay 1NC+1NO 110/127V EPN516

Phase out product: please contact your electrical wholesaler for availability

Accessories
Technical characteristics
Environmental value
Documentations

Complete your system

Auxiliary device for distribution board devices 2 products available

Technical characteristics

Rated current

16 A
Quiescent current

6 mA
Acceptable current rating AC1

16 A

Number of modules

1

Type of contacts

1NC+1NO
Cross-section flexible conductor

1 - 6 mm²
Cross-section rigid conductor

1.5 - 10 mm²
Number of contacts

1

Command voltage AC

110 - 127 V
Command voltage DC

48 - 48 V
Command voltage 2

48 - 48 V
Command voltage 1

110 - 110 V
Rated insulation voltage Ui

250 V
Rated operational voltage Ue

250 - 250 V

Frequency

50 - 60 Hz

Operating temperature

-5 - 40 °C
Storage/transport temperature

-40 - 80 °C

Type of connection

Screw terminal

Total power loss under IN

1.20 W
Inrush power absorbed

25 VA

Height

83 mm
Width

17.50 mm
Depth

63 mm

Max. load fluorescent lamp

800 VA
Max. load fluorescent lamp parallel compensated

900 VA

Number of NO contacts

1
Number of NC contacts

1
