EAN-Nr.

3250612271030

Packaging

1 piece

Weekly time switch 1 channel, digital, 2 modules EG103

Phase out product: please contact your electrical wholesaler for availability

Accessories
Technical characteristics
Documentations

Download the sheet

Technical characteristics

Rated operational voltage Ue

230 - 230 V

Frequency

50 - 50 Hz

230 V incandescent and halogen lamp

2,300 W

Power reserve in years

5 y
With network synchronisation

No
With quartz synchronisation

Yes
Number of function channels

1

Accuracy per day

1.50 s
With impulse programme

No
Number of channels

1

Type of contacts

1x changeover
Cross-section flexible conductor

1 - 6 mm²
Cross-section rigid conductor

1.5 - 10 mm²

Daily programme

No
Weekly programme

Yes
Annual programme

No

Operating temperature

-5 - 45 °C

Type of connection

With screw terminals
Function

Keylock by means of blocking key

Height

85 mm
Width

35 mm
Depth

64 mm

Number of modules

2

Minimum interval between 2 switching times

1 min

Downloads

Product Image EG103
Product datasheet

Hager Product data sheet EG103

Weekly time switch 1 channel, digital, 2 modules

PDF
Installation manual

Installation manual en-GB, fr-FR 2020-01-01

PDF

644,66 kB
Tool

Windows software for EG003 V 2.0.2

Tool International 2023-10-30

EXE

40,25 MB
Product data sheet

UK_MD_TDS_1channelelectimeswitch.pdf

Technical data sheet including characteristics for 1 channel electronic time switch weekly cycle.

PDF

139,27 kB

UK_MD_TDS_TimeSwitches.pdf

Technical data sheet including characteristics for time switches.

PDF

74,88 kB
Declaration of conformity

Declaration

Declaration of conformity International 2022-01-21

PDF

126,59 kB
