S.1/B.3/B.7 Push Button 3-gang, with Thermostat/Label, White/Polar White 75663780

Phase out product: please contact your electrical wholesaler for availability

Accessories
Technical characteristics
Environmental value
Documentations

Download the sheet

Complete your system

Must-have accessories

See all (12)

75040001

Bus coupling unit flush-mtd, KNX

13099909

Frame l. cut-out, S.1, p. white, matt, plastic

13098989

Frame l. cut-out, S.1, p. white glossy

13098982

Frame l. cut-out, S.1, white glossy

13096919

Frame l. cut-out, B.7, p. white matt, lacq.

13096914

Frame l. cut-out, B.7, al./p. white matt, al. anodised

Technical characteristics

Mounting on

Flush mounting

Operating temperature

-5 - 45 °C

With room temperature controller

Yes

Height

110.80 mm
Width

55.80 mm
Depth

13.85 mm

Number of actuation points

8

With LED indication

Yes

Colour

White
RAL code

1013
Material

Thermoplastic
Surface finish

Glossy

Has labelling field

Yes

With display

Yes

Function

For switch, push-button, dimmer, blind and thermostat functions, With valve protection function
Operating mode

Controller operating modes: comfort, standby, night and frost/heat protection mode
Protection

With dismantling protection
Temperature

Temperature measurement via internal and/or external sensor with mean value formation

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes
