    • 48046086
    EAN-Nr.
    4011334528333
    Packaging
    1 piece

    SCHUKO socket outlet/USB A-C Q.x, anthracite velvety, lacquered 48046086

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in
    Phase out product: please contact your electrical wholesaler for availability

    SCHUKO socket outlet/USB A-C Q.x, anthracite velvety, lacquered

    48046086

    • Technical characteristics
    • Environmental value
    • Documentations
    Download the sheet

    Technical characteristics

    Voltage
    • Rated voltage
      250 V
    • Output voltage
      4.75 - 5.25 V
    Electric current
    • Output current
      3,000 mA
    • Rated current
      16 A
    Frequency
    • Frequency
      50 - 50 Hz
    Power
    • Output power
      15 W
    • Power consumption standby
      0.05 W
    Materials
    • Colour
      Anthracite
    • RAL code
      7021
    • Surface finish
      Matt
    • Material
      Thermoplastic
    • Treatment
      Untreated
    Dimensions
    • Height
      71 mm
    • Width
      71 mm
    • Depth
      45 mm
    • Number of units
      1
    • Built-in depth flush-mounted boxes
      35 mm
    • Built-in depth
      32 mm
    Connection
    • Connector/plug type
      Plug-in terminal
    Installation, mounting
    • Mounting on
      Flush mounting
    Connectivity
    • Type of connection
      Plug-in connection
    • Mounting type
      Screw mounting, Claw mounting
    • Connector/plug type USB
      AC
    Equipment
    • Connector/plug type socket outlet
      SCHUKO
    • Rotated central insert
      No
    • With hinged lid
      No
    • With round protective earth pin
      No
    • With signal lamp
      No
    • With lock
      No
    Accessories
    • Has labelling field
      No
    Capacity
    • Number of modules
      1
    Safety
    • With enhanced contact protection
      Yes
    • Impact resistance IK
      IK02
    • Ingress Protection (IP) class
      IP20
    Functions
    • With orientation lighting
      No
    • With function lighting
      No
    Identification
    • With imprint
      No

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    Hager REACH declaration 48046086
    PDF
    Hager RoHS report 48046086
    PDF

    Downloads

    • Image 48046086 | Hager

      Product Image 48046086

    • Product datasheet

      Image Hager Product data sheet 48046086 | Hager

      Hager Product data sheet 48046086

      SCHUKO socket outlet/USB A-C Q.x, anthracite velvety, lacquered

      PDF

    • Installation manual

      Image Manual for 4804xx - SCHUKO/USB socket outlet A+C (EN-NL-SV, 2021-07) | Hager

      Manual for 4804xx - SCHUKO/USB socket outlet A+C (EN-NL-SV, 2021-07)

      Installation manual en-GB, nl-NL, sv-SE 2021-07-01

      PDF
      446,40 kB

    • Declaration of conformity

      Image Declaration of conformity en-GB, de-DE 2021-12-10 | Hager

      Declaration of conformity en-GB, de-DE 2021-12-10

      PDF
      276,13 kB
      Image Declaration of conformity en-GB, de-DE 2021-12-10 | Hager

      Declaration of conformity en-GB, de-DE 2021-12-10

      PDF
      276,09 kB
