SCHUKO soc.out.,enhncd contact prot.,mounting orient. var. in 45°step,B7,al.lacq 47491404

EAN-Nr.
4011334224419
Packaging
10 Pieces

Complete your system

Optional accessories

  • Accessories/spare parts for domestic switching devices 1 products available

Compatible products

  • Referenced by 150 products available

Technical characteristics

Electric current
  • Rated current
    16 A
Voltage
  • Rated voltage
    250 V
  • Nominal voltage
    250 - 250 V
Frequency
  • Frequency
    50 - 60 Hz
Materials
  • Colour
    Aluminium
  • RAL code
    9006
  • Surface finish
    Matt
  • Material
    Thermoplastic
  • Treatment
    Untreated, Varnished
Dimensions
  • Height
    71 mm
  • Width
    71 mm
  • Number of units
    1
  • Built-in depth
    32 mm
Connection
  • Connector/plug type
    Plug clamp
Installation, mounting
  • Mounting on
    Flush mounting
Connectivity
  • Type of connection
    Plug-in connection
  • Mounting type
    Screw mounting, Claw mounting
Equipment
  • Connector/plug type socket outlet
    SCHUKO
  • Rotated central insert
    No
  • With hinged lid
    No
  • With round protective earth pin
    No
  • With signal lamp
    No
  • With lock
    No
Accessories
  • Has labelling field
    Yes
Capacity
  • Number of modules
    1
Safety
  • With enhanced contact protection
    Yes
  • Impact resistance IK
    IK05
  • Ingress Protection (IP) class
    IP20
Functions
  • With orientation lighting
    No
  • With function lighting
    No
  • Related Systems
    S.x/B.x

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
