Aerial soc. 2hole throughpass soc., 10 dB 451510
EAN-Nr.
4011334424635
Packaging
10 Pieces
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Must-have accessories
See all (18)
Compatible products
-
Referenced by 542 products available
Mandatory accessories
-
103921Centre plate for aerial soc. 2hole, 1930/glass, black glossy
-
12038989Centre plate for aerial soc. 2-/3hole, S.1/B.3/B.7, p. white glossy
-
148602Central plate f. aerial soc. 2hole, splash-proteced flush-mtd IP44, white glossy
-
148609Central plate for aerial soc. 2hole, splash-proteced flush-mtd IP44, p. white
-
12032045Centre plate for aerial soc. 2-/3hole, R.1/R.3/R.classic, black glossy
-
12032089Centre plate for aerial soc. 2-/3hole, R.1/R.3/R.classic, p. white glossy
-
12031404Centre plate for aerial soc. 2-/3hole, B.7, al., matt, lacq.
-
12031606Centre plate for aerial soc. 2-/3hole, B.3/B.7, ant., matt
-
12031909Centre plate for aerial soc. 2-/3hole, S.1/B.3/B.7, p. white, matt, plastic
-
12038982Centre plate for aerial soc. 2-/3hole, S.1, white glossy
-
103920Centre plate for aerial soc. 2hole, 1930/glass, p. white glossy
-
12017014Centre plate for aerial soc. 2-/3hole, K.5, stainless steel, metal matt finish
-
12017013Centre plate for aerial soc. 2-/3hole, K.5, al., al. anodised
-
12017016Centre plate for aerial soc. 2-/3hole, K.1, ant. matt, lacq.
-
12017019Centre plate for aerial soc. 2-/3hole, K.1, p. white glossy
-
12036084Centre plate for aerial socket 2- and 3-hole, Q.x, alu velvety, lacquered
-
12036086Centre plate for aerial soc. 2-hole, Q.x, ant. velvety, lacq.
-
12036089Centre plate for aerial soc. 2-hole, Q.x, p. white velvety
Referenced by
-
10239959Frame 3gang hor., lab. field, S.1, al. matt
-
10119959Frame 1gang, lab. field, S.1, al. matt
-
10119969Frame 1gang, lab. field, S.1, ant., matt
-
10128912Frame 2gang vert., lab. field, S.1, white glossy
-
10128919Frame 2gang vert., lab. field, S.1, p. white glossy
-
10129919Frame 2gang vert., lab. field, S.1, p. white, matt, plastic
-
10129959Frame 2gang vert., lab. field, S.1, al. matt
-
10129969Frame 2gang vert., lab. field, S.1, ant., matt
-
10138912Frame 3gang vert., lab. field, S.1, white glossy
-
10138919Frame 3gang vert., lab. field, S.1, p. white glossy
-
10139919Frame 3gang vert., lab. field, S.1, p. white, matt, plastic
-
10228912Frame 2gang hor., lab. field, S.1, white glossy
-
10228919Frame 2gang hor., lab. field, S.1, p. white glossy
-
10229919Frame 2gang hor., lab. field, S.1, p. white, matt, plastic
-
10229959Frame 2gang hor., lab. field, S.1, al. matt
-
10229969Frame 2gang hor., lab. field, S.1, ant., matt
-
10238912Frame 3gang hor., lab. field, S.1, white glossy
-
10238919Frame 3gang hor., lab. field, S.1, p. white glossy
-
10239919Frame 3gang hor., lab. field, S.1, p. white, matt, plastic
-
10239969Frame 3gang hor., lab. field, S.1, ant., matt
Technical characteristics
Connectivity
-
Mounting typeScrew mounting
Attenuation
-
Tap loss at 2150 MHz10.50 dB
-
Tap loss at 860 MHz7.50 dB
-
Through loss 2150 MHz7 dB
-
Through loss 860 MHz4 dB
Connection
-
Connector/plug typePass-through socket
Frequency
-
Frequency bandwidth5 - 2,400 MHz
-
Broadband technology5 - 2,400 MHz
Equipment
-
Number of outputs2
Materials
-
MaterialMetal
Dimensions
-
Depth27.20 mm
-
Built-in depth40 mm
Installation, mounting
-
Mounting onFlush mounting
Texts
-
FunctionSuitable for HDTV
-
Type of connectionWith plug-in terminals
-
Supporting plate/supporting ringExternal eyelets on the supporting ring can be broken off for round designs
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet 451510
Aerial soc. 2hole throughpass soc., 10 dB
PDF -
Declaration of conformity
Declaration of conformity International 2023-08-08
PDF251,62 kB
