VGA soc. out., screw-in lift terminals, K.5, stainless steel matt, lacq. 3315417004
EAN-Nr.
4011334330455
Packaging
10 Pieces
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Cover frame for domestic switching devices 9 products available
Complete your system
-
13137004
Frame 1gang, K.5, stainless steel, metal matt finish
-
13237004Frame 2gang vert., K.5, stainless steel, metal matt finish
-
13637004Frame 2gang hor., K.5, stainless steel, metal matt finish
-
13737004Frame 3gang hor., K.5, stainless steel, metal matt finish
-
13837004Frame 4gang hor., K.5, stainless steel, metal matt finish
-
13937004Frame 5gang hor., K.5, stainless steel, metal matt finish
-
13337004Frame 3gang vert., K.5, stainless steel, metal matt finish
-
13437004Frame 4gang vert., K.5, stainless steel, metal matt finish
-
13537004Frame 5gang vert., K.5, stainless steel, metal matt finish
Technical characteristics
Connection
-
Connector/plug typeVGA
-
Number of connections1
Frequency
-
Frequency video160 MHz
Materials
-
ColourStainless steel
-
RAL code9022
-
Surface finishMatt
-
MaterialMetal, Plastic, Stainless steel
-
TreatmentVarnished
Dimensions
-
Height71 mm
-
Width71 mm
-
Depth23.50 mm
-
Built-in depth flush-mounted boxes13 mm
Connectivity
-
Mounting typeScrew mounting
Equipment
-
ShieldedYes
-
With dust coverNo
Safety
-
Ingress Protection (IP) classIP20
-
Impact resistance IKIK05
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet 3315417004
VGA soc. out., screw-in lift terminals, K.5, stainless steel matt, lacq.
PDF -
Installation manual
Manual for 33153xx-33154xx - Multimedia sockets (DE-EN, 2020-12)
Installation manual en-GB, de-DE 2023-01-06
PDF3,31 MB
Manual for 33153xx-33154xx - Multimedia sockets (DE-EN, 2023-03)
Installation manual en-GB, de-DE 2023-04-13
PDF3,31 MB
