Temp Controller, CO Contact, White • 20266089 | Hager
Location Middle-East

  • Better buildings. Better tomorrows.

    • Menu
    Account
    EAN-Nr.
    4011334316145
    Packaging
    1 piece

    Thermostat, change-over contact, centre plate, Q.x, p. white velvety 20266089

    Complete your system

    Compatible products

    • Referenced by 143 products available

    Technical characteristics

    Architecture
    • Control/operation element
      Rotative
    Electric current
    • Rated current
      5 A
    • Max. switching current
      10 A
    Voltage
    • Nominal voltage
      230-230 V
    Power supply
    • Supply voltage
      230 V AC
    Frequency
    • Frequency
      50 - 60 Hz
    Settings
    • Comfort temperature setpoint
      5 - 30 °C
    Materials
    • Colour
      Polar white
    • RAL code
      9010
    • Surface finish
      Velvety
    • Material
      Metal, Plastic
    • Treatment
      Untreated
    Dimensions
    • Height
      71 mm
    • Width
      71 mm
    • Depth
      47.50 mm
    Screen
    • With display
      No
    Equipment
    • Switching temperature difference
      0.50 K
    • Type of thermostat
      Room thermostat
    • Type of probe
      Bimetal
    • With heater
      Yes
    Connection
    • Type of contacts
      1x changeover
    Safety
    • Ingress Protection (IP) class
      IP20
    Compatibility
    • Type of HVAC control
      Heating, Cooling
    Use conditions
    • Energy efficiency class
      I (1%)

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    ka.line C: RTC 60x60 230V white
    PDF
    6,02 MB
    Hager REACH declaration 20266089
    PDF
    Hager RoHS report 20266089
    PDF

    Downloads

    More documentation
