The Hager internal corner, overlapping, for LFS 60x150 trunking delivers neat 90° inside transitions with concealed overlap for continuous cable protection and a clean finish. Moulded varnished steel (RAL 9016 traffic white) offers durability, IK08 impact resistance and IP30 protection. Dimensions 60×150 mm (a=50 mm). Operating -5 to 90°C. Ideal for residential and commercial cable routing.
EAN
4012740007573
Packaging
5
Internal corner overlapping steel LFS 60x100 Traffic white RAL9016 IP30 IK08 LFS6015049016
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Accessories
-
Type of accessoryMoulded
Settings
-
Angle range90 - 90
Dimensions
-
Height60 mm
-
Width150 mm
-
Measurement a50 mm
Materials
-
MaterialSteel
-
TreatmentVarnished
-
ColourTraffic white
-
RAL code9016
Safety
-
Impact resistance IKIK08
-
Ingress Protection (IP) classIP30
Standards
-
Suitable for functional integrity according to DIN4102-12No
Use conditions
-
Operating temperature-5 - 90 °C
Equipment
-
With protective filmNo
Configuration
-
OverlappingYes
-
Related SeriesLFS 60x150
