The Hager LFS 60x150 External Corner (overlapping) in galvanized steel delivers a clean 90° turn for trunking on steel/plaster walls. Size 60×150 mm (a=50 mm). Overlap covers cuts for a seamless, protected route. IK08 and IP30 for robust indoor use, -5…60 °C. Zinc-coated for corrosion resistance. Moulded design speeds installation and maintains LFS 60x150 continuity at corners.
EAN
4012740023191
Packaging
8
Overlapping T-piece LFS 60x100 galvanized steel DIN 4102-12 IP30 IK08 LFS601503VERZ
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Dimensions
-
Height60 mm
-
Width150 mm
-
Measurement a50 mm
Accessories
-
Type of accessoryMoulded
Settings
-
Angle range90 - 90
Materials
-
MaterialSteel
-
TreatmentGalvanised
-
ColourZinc
Safety
-
Impact resistance IKIK08
-
Ingress Protection (IP) classIP30
Standards
-
Suitable for functional integrity according to DIN4102-12No
Use conditions
-
Operating temperature-5 - 60 °C
Equipment
-
With protective filmNo
Configuration
-
OverlappingYes
-
Related SeriesLFS 60x150
