The Hager ATS with Energy Management 4x1600A ensures uninterrupted power by automatically transferring between sources while optimizing energy use. Rated 1600 A, 380-415 V, and AC-1 power up to 1,053 kW at 400 V, it withstands 100 kA (gl/gG). 4-pole, fixed built-in design fits DIN-rail distribution boards—ideal for large commercial and industrial switchboards.
EAN
3250613131906
Packaging
1 Piece
Motorized transfer switch 4P 1250A 100kA 380-415V fixed built-in HIC492E
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Accessories/spare parts for low-voltage switch technology 3 products available
Technical properties
Voltage
-
Rated operational voltage Ue380 - 415 V
Electric current
-
Rated current1600 A
-
Rated conditional short-circuit current Icc with gl-gG fuses100 kA
Power
-
Rated operational power under 400 V AC AC11053000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailYes
-
Suitable for distribution boardYes
