The Hager ATS with energy management, 4‑pole 1000 A, ensures seamless source transfer and optimized load control for critical power continuity. Rated 380-415 V with 658 kW at 400 V AC1 and 100 kA Icc (gG fuses), it offers high fault withstand and reliability. Fixed built-in construction, suitable for DIN rail and distribution boards. Ideal for large commercial and industrial mains‑to‑backup applications.
EAN
3250613131869
Packaging
1 Piece
Automatic transfer switch 4P 1600A 100kA Fixed built-in 380-415V HIC490E
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Accessories/spare parts for low-voltage switch technology 3 products available
Technical properties
Voltage
-
Rated operational voltage Ue380 - 415 V
Electric current
-
Rated current1000 A
-
Rated conditional short-circuit current Icc with gl-gG fuses100 kA
Power
-
Rated operational power under 400 V AC AC1658000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailYes
-
Suitable for distribution boardYes
Downloads
More documentation
