The Hager 4‑pole 125 A Automatic Transfer Switch ensures seamless changeover between mains and backup in 380-415 V three‑phase systems. With 100 kA conditional short‑circuit withstand (gG fuses) and 82 kW AC‑1 at 400 V, it offers robust reliability. Fixed built‑in design for mounting plate, suitable for distribution boards (not DIN rail). Ideal for ensuring power continuity in commercial and industrial installations.
EAN
3250613131739
Packaging
1 Piece
Automatic transfer switch 4P 160A 380-415V 100kA Fixed built-in HIC412G
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Accessories/spare parts for low-voltage switch technology 2 products available
Technical properties
Voltage
-
Rated operational voltage Ue380 - 415 V
Electric current
-
Rated current IN125 A
-
Rated conditional short-circuit current Icc with gl-gG fuses100 kA
Power
-
Rated operational power under 400 V AC AC182000 W
Architecture
-
Number of poles4
-
Device construction typeFixed built-in
Compatibility
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Installation, mounting
-
Mounting onMounting plate
